Huadong cable group are professional and bigest cables and wire factory in china , then we main products are low/medium/high voltages abc cable ,power cable ,acsr ,aaac ,accc,rubber cable ,control cable ,welding cable ,flat cable , house wire and so on .with high quality and best cheap price . and best service for you . if you are interested and hope to open work with us ,we will give you best price. feel free to talk with me .

email:sales@hlcables.com
tel :86-0371-66766667

Product feature:

  Conductor Type: copper  Solid,stranded           Insulation Material: PVC         Jacket: PVC

Color: Black or as per requirement,           Standard: IEC 60227, BS 6004, VDE0281, JB/T8734     Cores:2C, 3C, 2C+E, 3C+E

Certification: ISO9001/ISO14001 /OHSAS18001/CCC     Standard: AS/NZS 5000.2

Type Twin and Earth Cable, Flat Twin and Earth , LSF, LSOH, OHLS Twin & Earth Cable

Range of Nominal cross section: 1.0 mm2 ~ 16 mm2

Application: These cables are used for general wiring, unenclosed, enclosed in conduit, buried direct or in underground ducts for domestic, commercial and industrial aaplications where not subject to mechanical damage.

Constructions:

Conductor: Class 1/2 Plain annealed copper wires, solid or stranded

Insulation: V-90 PVC           Sheath: 3V-90 PVC easy tear

Core color: red and black for active core, green/yellow for earth core, white for sheath

Max. Operating Temperature: 90°C

Core Colours: Red, Black & Green/Yellow;     Red, Blue, White & Green/Yellow.

parameter:

No.of Cores x	Main	Normal	Normal	Earth	Over	Type
Nominal Cross	Conductor	Thickness	Thickness	Conductor	Diameter
Sectional Area	Type	of Insulation	of Jacket	Area	of Cable
(mm2 )		(mm)	(mm)	(mm2 )	(mm)
1	solid	0.6	0.9	1	8.9*4.2	2C+E
1.5	Strand	0.6	0.9	1.5	9.9*4.5	2C+E
2.5	Strand	0.7	1	2.5	11.8*5.4	2C+E
2.5	Strand	0.7	1	2.5	12.2*54	2C+E
4	Strand	0.8	1.1	2.5	13.9*6.3	2C+E
6	Strand	0.8	1.1	2.5	15*6.9	2C+E
1.5	Strand	0.6	0.9	1.5	12.6*4.5	3C+E
1	solid	0.6	0.9		6.5*4.2	2C
2.5	Strand	0.7	1		8.9*54	2C
4	Strand	0.8	1.1		10.5*6.3	2C
1	solid	0.6	0.8		4	Single core
4	Strand	0.8	0.9		6	Single core

rhh cable

Application Suitable for use as follows:

• Southwire Type RHH or RHW-2 or USE-2 conductors are used with conduit as specified  in the National Electrical Code 1

• When used as Type USE-2, conductor is suitable for use as underground service entrance cable for direct burial at conductor temperatures not to exceed 90°C

• When used as RHH, conductor temperatures shall not exceed 90°C in dry locations

• When used as RHW-2 or USE-2, conductor temperatures shall not exceed 90°C in wet or dry locations

• Voltage rating for RHH or RHW-2 or USE-2 conductors is 600 volts

Standards&References:

Southwire Type RHH or RHW-2 or USE-2 meets or exceeds UL Standard 44 (for RHH or

RHW-2), UL Standard 854 (for USE-2), Federal Specification A-A-59544, and requirements of the National Electrical Code.

Construction:

• Southwire Type RHH or RHW-2 or USE-2 copper conductors are annealed (soft) copper.

• Insulation is an abrasion, moisture, heat, and sunlight resistant black cross-linked  polyethylene (XLP).

 Specification:

• Conductors shall be UL-listed Type RHH or RHW-2 or USE-2, suitable for operation at 600 volts or less in wet or dry locations, including direct burial in the earth.

• Conductors shall be annealed copper, cross-linked polyethylene (XLP) insulated,

as manufactured by Southwire Company or approved equal.

H07RN8-F copper rubber insulated/jacket cable.

copper rubber insulated/jacket H07RN8-F rubber cable Structure:

standard：HD22.16 S1,VDE-0282 Part-16,CEI 20-19 p.16,

Conductor:Stranded copper conductor, class 5 according to DIN VDE 0295/IEC 60228.

Insulation:Rubber type EI4 according to DIN VDE 0282 Part 16.

 Inner Sheatd: (for ≥ 10 mm² or more than 5 cores)

Rubber type EM2/EM3 according to DIN VDE 0282 Part 16.

Outer Sheath: Rubber type EM2 according to DIN VDE 0282 Part 16.

Voltage Rating:450/750V

copper rubber insulated/jacket H07RN8-F rubber cable description:

H07RN8 -F cable is  highly flexible weather- and oil-resistant cable, that can be constantly submerged in fresh water up to 10 m depth with a maximum water temperature up to 40°C for the connection of submersible pumps or similiar applications, where the mechanical stress is of medium hard character.

copper rubber insulated/jacket H07RN8-F rubber cable working:

H07RN8 -F is also suitable in spaces with explosion risks, dry or humid spaces, outdoors e.g. in agricultural buildings and for temporary installations in working sites. Also for fixed installation in temporary buildings and cabins. Use up to 1000 V AC is permitted for fixed, protected installation (in conduit or appliances) and also for motor connections of hoisting motors and the like. Max direct voltage 742/1238 V DC.

copper rubber insulated/jacket H07RN8-F rubber cable Application rangeFor connecting electrical equipment in industrial water, e.g. floater switches Flexible applications in indoor and outdoor swimming pools Suitable for use with submersible pumpsDry and damp interiors, as well as outdoors

and in industrial water.

copper rubber insulated/jacket H07RN8-F rubber cable Benefits

·Temporary use in water: a maximum of 2 weeks at a time (transversely waterproof), subsequent drying-out required

·Immersion depth of 10 m

·According to HD 516/VDE 0298-300, underwater use prohibited in areas with shipping traffic, moving water or where there is a risk of dangerous, mechanical damage

·Type-compliant versions -certified with “” testing and certification mark for accelerated granting of approvals if final application of cable is within the European CENELEC area

pcopper rubber insulated/jacket H07RN8-F rubber cable aramter:

No./Ara	Minimum OD	Maximum OD	Nominal Weight
No. ×mm2	mm	mm	kg/km
1×1.5	5.7	6.7	60
2×1.5	8.5	10.5	120
3G1.5	9.2	11.2	170
4G1.5	10.2	12.5	210
5G1.5	11.2	13.5	260
7G1.5	14	17	360
12G1.5	17.6	20.5	515
19G1.5	20.7	26.3	795
24G1.5	24.3	28.5	920
1×2.5	6.3	7.5	75
2×2.5	10.2	12.5	170
3G2.5	10.9	13	230
4G2.5	12.1	14.5	290
5G2.5	13.3	16	360
7G2.5	17	20	510
12G2.5	20.6	23.5	740
19G2.5	24.4	30.9	1190
24G2.5	28.8	33	1525
