35mm 50mm 95mm 120mm 150mm 185mm 240mm XLPE SWA PVC power supply cable Armoured 4 Core Power .
please leave me messages ,
we will send you the price list .
email id :sales@hlcables.com

IEC standard 450-750V 35mm2 flexible welding cable,
high quality cables with best cheapest factory price , you will get a good partner that have biggest factory in china .
all of my friends on fb,if you want price list , please give me your email id . thank you .
email is sales@hlcables.com

running for life ,huadong cable factory run ahead , and product high quality lv mv hv power cables ,house wires , abc cables, rubber cable s , control cabels , opgw , and welcome all of my friend ask me price list . thank you .
email id :sales@hlcables.com

NA2XRY 4 cores 0.6/1 KV International : IEC 60502-1 16~300mm2.

NA2XRY

• Voltage：0.6/1 KV
• Core：4 cores
• Size： 16~300mm2
• Conductor： Aluminum
• Insulation： XLPE

Related Recommendations

ominal	Number and	Nominal	Maximum Permissible		Standard	Weight	Delivery
Cross Sectional	Diameter of Wire	Overall	Current Rating		Delivery	per Standard	on Wooden
Area		Diameter	Amp		Length	Delivery L	Drum
mm²	No x mm	mm	In Ground @ 20°C	In Air @ 30°C	m	kg
4 x 16	7 x 1.70	23.1	87	77	1000	803	R14
4 x 25	7 x 2.14	27.2	111	97	1000	1078	R16
4 x 35	7 x 2.58	25.6	134	120	1000	1147	R16
4 x 50	19 x 1.83	28.7	160	146	1000	1405	R16
4 x 70	19 x 2.20	32.6	197	187	1000	1805	R18
4 x 95	19 x 2.58	36.6	234	227	500	1155	R18
4 x 120	37 x 2.08	40.1	266	263	500	1386	R18
4 x 150	37 x 2.30	44.4	300	304	500	1673	R20
4 x 185	37 x 2.58	49.2	337	347	500	1793	R22
4 x 240	61 x 2.30	52.7	389	409	500	2507	R25
4 x 300	61 x 2.58	60.2	440	471	400	2443	R25

Construction characteristics
Insulation	XLPE (Cross-linked Polyethylene)
Outer sheath	PVC
Inner sheath	PVC
Electrical characteristics
Rated Voltage Uo/U (Um)	0.6/1 kV
Max. system voltage, 1-phase grounded	0.7kV
Max. system voltage 3 phases (Um)	1.2kV
Mechanical characteristics
Mechanical resistance to impacts	Very good
Usage characteristics
U.V resistance	if required
Flame retardant	IEC 60332-3 Cat. A
Bending factor when laying	10(xD)
Minimum installation temperature	90°C
Max. conductor temperature in service	90°C
Short-circuit max. conductor temperature	250°C

U500 SV (H07 V-K)

• Voltage：450/750V
• Core：single or multi
• Size： 0.75~150mm2
• Conductor： Copper
• Insulation： PVC

Related Recommendations

• H07V-U
• H07V-R
• H07V-K
• H05V-K
• U500VGV (A05VV-U)
• U500 SV1V (H05VV-F)

Standards

International :  IEC 60227-2

National :  NF C 32-201/3

Description

Application

H07V-K cors are used for panels and cabinets stranding.

Installation

Open air, in conduit, in cable trunking, in cable ducting.

email is sales@hlcables.com

tel is 0086-0371-66766667

Construction characteristics
Insulation	PVC
Conductor material	Bare copper
Electrical characteristics
Rated Voltage Uo/U (Um)	450 / 750 V
Mechanical characteristics
Mechanical resistance to impacts	Low
Cable flexibility	Flexible
Usage characteristics
Max. conductor temperature in service	70°C
Short-circuit max. conductor temperature	160°C
Operating temperature, range	-5 .. 60°C
Weather resistance	Good
Flame retardant	C2, NF C 32-070
Chemical resistance	Accidental
Water proof	Accidental
Bending factor when laying	4(xD)

IEC60227 copper House Cable

Product feature:

Conductor Material/Type: copper Solid/stranded/flexible        Core:  1/2/3/4, Voltage: 300/500v 450/750v,         Insulation/Jacket Material: PVC

Style: Flat/round/twin and earth wire,        Standard: IEC, BS, UL, VDE, AS/NZS, JIS, etc,       Specification: Electric Wire 2.5mm2, 1.5mm2,etc

Length: 100M 200M 300M 500M          Color: Green Red Yellow Black Green etc.

Description:

1.Max. Permissible Continuous Operation Temperature of The Conductor: 70°C;      2..The Ambient Temperature Under Installation Should Not Below 0°C

3.Impedance (ohms): 100±2ohm       4. Fixed -40°C to 90°C / Flexing -2

Application:

House wire Cables are suitable for household electrical appliances, small electric power tools,  AC rated voltage up to and including 450/750V,  and below the small household electrical appliances, electric tools, instruments and apparatuses and lighting devices, which is used for connecting power line.

Parameter 1:

Nominal	Conductor	Nominal	Max.overall	Condcutor	Min.insulated	Weight
sectional area	No/Dia.	Insulated thickness	Dia.	Resistance at	resistance at	Kg/km
mm2	mm	mm	mm	20	70MΩ/km
2.5	9/0.41	0.8	4.2	7.41	0.011	33
4	19/0.52	0.8	4.8	4.61	0.009	48
6	19/0.64	0.8	5.6	3.08	0.0084	68
10	49/0.52	1	7.6	1.83	0.0072	115
16	49/0.64	1	8.8	1.15	0.0062	176
25	98/0.58	1.2	11	0.727	0.0058	272
35	133/0.58	1.2	12.5	0.524	0.0052	384
50	133/0.68	1.4	16.5	0.387	0.0051	510
70	189/0.68	1.4	16.5	0.268	0.0045	714
95	259/0.68	1.6	19.5	0.139	0.0035	965
120	259/0.76	1.8	22	0.153	0.0032	1210
150	259/0.85	1.8	25	0.124	0.0032        1348

Parameter 2:

Product Name	Solid/flexible Copper PVC house building wire Cable
Product standard	AS/NZS 5000.2 / IEC60227
Core	1/2/3/4cores
Operating temperature	-40 °C~90°C
Type of conductor	Class 5
Material of conductor	Copper/Aluminum
Material of insulation	PVC 5V-90/Rubber
Color of core insulation	Red/White/Blue/Black/Green/Yellow(Optional)
Material and Color of Jacket	PVC/Rubber/As your requirement
Rated Voltage	250/440V  300/500V  450/750V
Advantage	Easy to strip and terminate
Section	0.75mm2~240mm2
Popular Application	Fire Alarm / OWS & EWIS panels to detectors / Speakers / Horns / Field modules
